ARB Summit Bullbar

ARB



The all new Summit bar continues the ARB tradition of pioneering innovation and our relentless pursuit on quality. Summit is a modern interpretation of the renowned ARB Deluxe bar, styled to complement modern dual cab and wagon vehicles through a fresh, contemporary design language.

Building upon our proven air bag compatible bull bar mounting architecture, the Summit bar incorporates unique design features such as a 30mm edge radius on the wings and centre pan, wider press formed cover straps, 60.3mm top tubing, two piece polyethylene buffers and redesigned fog light surrounds (option for LED or halogen lights).

Resulting in the most visually impressive frontal protection system on the market.

FEATURES

  • Wing Design - The furthest most point from the chassis and often the point of impact in an animal strike, the wing area is by far the most vulnerable. ARB pioneered the multi fold upswept and tapered wing design, which provides an enormous amount of strength and maintains an optimum approach angle.
  • Wider Edge Radius - A 30mm wing and centre section edge radius offers increased strength while complementing modern vehicle design.
  • Hi-Lift Jacking Points - Eliminating the need for a mounting bracket, Hi-Lift jacking points are integrated into the design of Summit bull bars.
  • CB Aerial Brackets - The Summit bull bar incorporates two CB aerial brackets welded behind the top cross tube. Custom fit, clamp on brackets are also available for additional antenna mounting.
  • Winch Compatibility - Mounting a winch to a vehicle requires a properly supported structure that is designed to accommodate the stresses of winching. When using a snatch block to increase winching capacity, the forces are multiplied to several times the rated capacity of the winch. The ARB Summit bar features the option of fitting a winch, and is designed and tested to endure and exceed such loads.
  • Press formed  top pan and cover - Press forming has been utilised to create a stronger centre pan that features smooth, continuous edges. A press formed aluminium winch cover panel finishes off the bar for when a winch is not installed.
  • Split Pan Design -The wide, split pan design enhances the strength of the bar, while providing the radiator and engine with a massive amount of air flow. An integrated winch clutch opening makes winch operation simple.
  • Steel Uprights - Each bull bar upright is cut from a single sheet of steel and extends from the top tube through to the bumper section and actually forms part of the bar to chassis mount. This process ensures the whole outer frame receives the maximum possible support. Wide, press formed cover straps are then welded onto each upright to ensure there are no exposed sharp edges.
  • Air Bag Compatible
  • Optional Fog Lights - Perfect for driving in inclement weather, these fog lights (LED and halogen options available) provide a broad spread of light to illuminate the road ahead.
  • Larger Tubing - 60.3mm mandrel steel tubing provides increased frontal protection, as well offering greater visual styling to modern four wheel drive vehicles.
  • L.E.D Indicators & Clearance lights - 12 high intensity yellow LEDs and 4 white LEDs provide increased light output in all conditions.

Enquire for pricing on these bars to suit your vehicle

Enquire Here

SKU: SUMMIT TAGS: Vehicle Protection, Bull Bars
